Our wires mainly made of molybdenum and tungsten are required anywhere unique material properties are in demand whether in lamps, coating systems, satellites, or medical technology.



Tungsten is widely used as refractory metals. In wire form, tungsten wire is essential for the production of lighting products and other goods where its high temperature properties are of use. Among its properties are a melting point of 3410° C, a low coefficient of thermal expansion and low vapor pressure at elevated temperatures along with good electrical and thermal conductivity.



Molybdenum wire is widely used for CNC EDM cutting. It can also be used for electric light source, electrode heating elements, high-temperature components, wire-electrode cutting, spraying for auto parts, it has high melting point, good thermal conductivity properties and Resistance of high-temperature.



Specification Reference



Product

Specification

Tolerance

Density

Tungsten Wire

d≥0.3mm

±0.02mm

19.1g/cm³

Molybdenum Wire

d≥0.025

±0.0015

10.2g/cm³

Note:we also provide customized service according to the drawings





 Physical and mechanical product properties

Diameter (mm)

Tensile strength (MPa)

0.30 - 0.49

1000 - 1300

0.50 - 0.79

800 - 1200

0.80 - 1.49

750 - 1100

1.50 - 3.99

650 - 1000

4.00 - 10.0

> 600



Integrated process control from powder metallurgy to wire drawing

Oxide - Reduction - Mixing alloys - Pressing - Sintering - Forming - Heat treatment - Mechanical processing - Quality assurance



We do everything ourselves to complete wire-making process internally. Starting with basics to the end item, plus creating new materials. This ensures top quality for our wires.
